LED-PAR36/RED 10~30V 9W Red
- Brand: Norman Lamps
- Product Code: LED-PAR36/RED
- UPC Code: 600300321661
-
$24.50
The Norman Lamps LED-PAR36/RED is a 9W LED PAR36 reflector lamp that delivers vivid red-colored illumination across a 120-degree very wide flood beam, producing 900 lumens of red light output. Designed as a direct LED replacement for 50W halogen PAR36 bulbs, it consumes a fraction of the energy while providing up to 50,000 life hours of reliable, long-lasting performance.
This LED PAR36 lamp operates on any input voltage between 10 and 30 volts AC or DC, making it highly versatile for use in a wide range of low-voltage landscape, architectural, theatrical, holiday, and specialty lighting systems. The screw terminal base provides a secure, weather-resistant connection suited to permanent and semi-permanent outdoor installations.
Built to perform in demanding environments, the LED-PAR36/RED carries an IP65 outdoor rating, meaning it is fully dustproof and protected against water jets from any direction. The lamp is not dimmable and draws 0.75A at 12V. It measures 4.50 inches in diameter and 2.87 inches in length, conforming to the standard PAR36 reflector form factor. CE and RoHS certifications confirm compliance with safety and environmental standards. Cases of 10 are available for larger installations.
- 9W LED PAR36 reflector lamp emitting vivid red light at 900lm — replaces 50W halogen PAR36 bulbs
- Wide 10-30V AC/DC input range suits landscape, architectural, theatrical, holiday, and specialty low-voltage systems
- 120-degree very wide flood beam spread with screw terminal base for secure, permanent connections
- IP65 outdoor rated and waterproof — dustproof and protected against water jets for reliable outdoor use
- 50,000 life hours of long-lasting LED performance; CE and RoHS certified
- Non-dimmable; draws 0.75A @12V; 4.50 in. diameter x 2.87 in. length; available in cases of 10
| Detailed Specifications | |
| Voltage | 10-30V |
| Wattage | 9W |
| Type | LED PAR36 |
| Lumens | 900 |
| Replaces | 50W Halogen PAR36 Bulb |
| Certifications | CE, RoHS |
| Beam Spread | 120 Degree |
| Lamp Shape | Reflector |
| Length | 2.87 in. |
| Diameter | 4.50 in. |
| Base Type | Screw Terminals |
| Average Life Hours | 50,000 |
| Case Quantity | Order 10 for a full case |
| Color Emitted | Red |
| Is It Dimmable? | No |
| Current | 0.75A @12V |
| Viewing Angle | Very Wide Flood |
| Features | Waterproof, IP 65 Outdoor Rated. |
